The types of plate rolling machines are different due to different fields of use. From the number of rolls, there are three roll plate bending machine and four roll plate bending machine. The three roll plate rolling machine is also divided into symmetrical three roll plate rolling machine, horizontal downward adjustment three roll plate rolling machine, arc downward adjustment three roll plate rolling machine, and upper roll three roll plate rolling machine. It is divided into mechanical type and hydraulic type in terms of transmission.

Large upper roll plate rolling machine

The main features of the large upper roll bending machine are: bending process with superior product accuracy, high-precision end pre bending, continuous bending without back angle, digital control human-computer dialogue control interface for bending process, intelligent operation of physical bending process software, human-computer dialogue window, and automatic compensation for bending process. Single person operation, safe, convenient and rich bending shapes have different shapes such as rolled O shape, U shape, multi segment R shape, etc

Medium upper roll plate rolling machine

The main features of the medium-sized upper roll bending machine are: bending process with superior product accuracy, high-precision end pre bending, continuous bending without back angle, digital control human-computer dialogue control interface for bending process, intelligent operation of physical bending process software, human-computer dialogue window, and automatic compensation for bending process. Single person operation, safe, convenient and rich bending shapes have different shapes such as rolled O shape, U shape, multi segment R shape, etc

Small upper roll plate rolling machine

The main features of the small upper roll bending machine are: bending process with superior product accuracy, high-precision end pre bending, continuous bending without back angle, digital control human-computer dialogue control interface for bending process, intelligent operation of physical bending process software, human-computer dialogue window, and automatic compensation for bending process. Single person operation, safe, convenient and rich bending shapes have different shapes such as rolled O shape, U shape, multi segment R shape, etc

Ship three roll symmetrical plate rolling machine

The main features of the ship's three roll symmetric plate bending machine are: bending process with superior product accuracy, high-precision end pre bending, continuous bending without back angle, digital control human-machine dialogue control interface for bending process, intelligent operation of physical bending process software, human-machine dialogue window, and automatic compensation for bending process. Single person operation, safe, convenient and rich bending shapes have different shapes such as rolled O shape, U shape, multi segment R shape, etc

Upper roll CNC plate rolling machine for oil tanker

The main features of the upper roll CNC plate bending machine for oil tank cars are: superior product precision * bending process, high-precision end pre bending, continuous bending without back angle, digital control man-machine dialogue control interface for bending process, intelligent operation of physical bending process software, man-machine dialogue window, and automatic compensation for bending process. Single person operation, safe, convenient and rich bending shapes are different from rolled O type, U type, multi section R

Three roll plate bending machine

There are mechanical and hydraulic three roll bending machines: mechanical three roll bending machines are divided into symmetric and asymmetric

Mechanical three roll symmetric plate rolling machine: mechanical three roll symmetric plate rolling machine Performance characteristics: the machine is of three roll symmetric structure. The upper roll makes vertical lifting movement at the symmetrical position of two lower rolls, which is obtained through the transmission of screw thread and worm. The two lower rolls make rotary movement. The output gear of the reducer meshes with the lower roll gear to provide torque for rolling plates. The disadvantage of this machine is that the end of the sheet needs to be pre bent by other equipment.

Mechanical three roll asymmetric plate rolling machine:

Main features of mechanical three roll asymmetric plate rolling machine: the machine is of three roll asymmetric structure, with the upper roll as the main drive and the lower roll as the vertical lifting motion to clamp the plate, and it is meshed with the upper roll gear through the lower roll gear as the main drive; The side roll is inclined and lifted, with double functions of pre bending and rolling. Compact structure, convenient operation and maintenance. Technical parameters: specification, model, rolling plate, zui thickness

Hydraulic three roll plate bending machine:

The main features of the hydraulic three roll symmetric plate rolling machine are as follows: the upper roll of the machine can rise and fall vertically, and the hydraulic transmission of the vertical rise and fall is obtained by acting on the piston rod by the hydraulic oil in the hydraulic cylinder; The lower roll is driven by rotation and meshed with the output gear of the reducer to provide torque for the coil. The lower part of the lower roll is provided with an adjustable idler. The upper roll is in the shape of a drum, which improves the straightness of the products. It is suitable for cans with super long specifications and various cross section shapes

It is an upward adjustable symmetrical three roll plate bending machine, which can roll metal plates into round, arc and conical workpieces within a certain range. The two lower rolls of this machine are driving rolls, and the upper roll is driven roll. It is widely used in shipbuilding, boiler, aviation, hydropower, chemical, metal structure and machinery manufacturing industries.

It is suitable for the bending deformation of metal plates. It can roll round, arc and conical workpieces within a certain range. It also has the pre bending function at the end of the plate. The two lower rolls of this model are driving rolls that can move horizontally, and the upper roll is driven rolls that can move up and down. The moving modes are mechanical and hydraulic. The transmission shafts are connected by universal couplings.

Mechanical three roll symmetrical plate rolling machine

Performance characteristics of mechanical three roll symmetric plate rolling machine. The disadvantage of this machine is that the end of the sheet needs to be pre bent by other equipment.

Mechanical three roll asymmetric plate rolling machine

Main features of mechanical three roll asymmetric plate rolling machine: the machine is of three roll asymmetric structure, with the upper roll as the main drive and the lower roll as the vertical lifting motion to clamp the plate, and it is meshed with the upper roll gear through the lower roll gear as the main drive; The side roll is inclined and lifted, with double functions of pre bending and rolling. Compact structure, convenient operation and maintenance. Hydraulic three roll symmetrical plate rolling machine

The main features of the hydraulic three roll symmetric plate rolling machine are as follows: the upper roll of the machine can rise and fall vertically, and the hydraulic transmission of the vertical rise and fall is obtained by acting on the piston rod by the hydraulic oil in the hydraulic cylinder; The lower roll is driven by rotation and meshed with the output gear of the reducer to provide torque for the coil. The lower part of the lower roll is provided with an adjustable idler.
